insert a 3d layout of another file

[Zanna91]

Hello everyone, I am here because I would need to insert a 3d model in the print layout with its views.

e.g.

Thank you:



[PlannerRoad]

create a window for every view.



[Tristan]

on autocad or on draftsight?? If you use autocad, what version are we talking about?



[Zanna91]

create a window for every view.

Okay, but I don't get to figure out how to import the 3d model into the layout.

@tristan: use autocad version 2007, but if you need it mandatory 2012 I can try to ask someone. :smile:

Thank you.



[PlannerRoad]

Okay, but I don't get to figure out how to import the 3d model into the layout.... .

in each window you can set the viewpoint you want.
enter the window and place yourself in the 3d view type you prefer.



[Zanna91]

Yes, I understood how the various windows fit with the views....I think I've explained badly.
I have a dwg with all sections and a dwg with the model in 3d, I would like to import into my dwg where all sections are present and the layout the model 3d.

I hope I've been more accurate. :finger:

Thank you.



[xxfast]

Yes, I understood how the various windows fit with the views....I think I've explained badly.
I have a dwg with all sections and a dwg with the model in 3d, I would like to import into my dwg where all sections are present and the layout the model 3d.

I hope I've been more accurate. :finger:

Thank you.

copy command and then paste.
you can do in different ways, from model or leyout.
you can also copy from a dwg to a layout of another dwg.
you have so many ways to do it.. .



[Zanna91]

solved. Thanks :finger:



[Zanna91]

one last thing I would like to know, can you enter the reference number in the 3d model as in the previously posted image?

Thank you.



[PlannerRoad]

one last thing I would like to know, can you enter the reference number in the 3d model as in the previously posted image?

Thank you.

the reference number of what?
in any case the command to enter certain values is fielded



[numero1]

I believe that zanna refers to the document number in 3d.
if this dwg file is called a7b per e.g., such number must appear in the table at 2d.
Hi.



[Zanna91]

I mean this:

yes that with autocad mechanical it is possible to realize these reference numbers with the command amballoon but with lt is possible?

Thank you.



[Tristan]

uses multidirectors
